CLASSIC + CORAL set a silver detail, everyday comfort
CLASSIC features a white body with a decorative silver trim. Descaling, odour absorption and two user profiles support everyday comfort.The CORAL frame has a factory-prepared cleansing-water feed to simplify installation and enables automatic flushing. A conventional wall flush button is included.
Front and rear wash
Warm water, adjustable flow.
Warm air drying
Adjustable drying temperature.
Heated seat
Set the temperature to your preference.
Three elements in one set
CLASSIC 4050FW
A white body with silver trim and a duroplast seat and lid. Descaling, odour absorption and two user profiles.
CORAL
Flushing cistern and a factory-routed hose for the cleansing system.
CORAL BLACK
A conventional push button. Manual flushing also works without electricity.
Less work routing the water supply
The frame has factory-separated supplies for flushing and cleansing water. An additional hose runs through a dedicated channel, so the installer does not need to add a tee fitting or route a separate pipe behind the enclosure to the shower toilet.
Automatic flushing after use
The dedicated CORAL concealed cistern system enables automatic flushing about 5 seconds after you stand up, even without using the cleansing functions. Automatic flushing requires power and a connection between the toilet and the frame controller.
Quiet operation and durable components
The flushing system is designed for discreet, reliable performance. A sturdy frame provides stability, while high-quality internal components support the long service life of the concealed installation.
Easy servicing and spare parts
Removing the flush plate gives you access to key components without disturbing the bathroom finishes. We provide long-term access to spare parts, so individual components can be replaced when needed instead of the entire frame.
The wall button works without electricity. The toilet’s cleansing and automatic functions require power.
Considered details. Convenient care.
Descaling, odour absorption and personal settings support everyday comfort. Choose the finish that suits your bathroom.
White with a silver accent
Silver trim on the upper body and the way the lid meets the front edge give CLASSIC its distinctive appearance.
Effective descaling
A descaling programme and a separate solution reservoir help reduce limescale, keep the water system clear and extend the service life of its components.
Odour absorption
Easy access to the container of granular activated carbon lets you replace its contents and maintain effective odour absorption throughout the toilet’s service life.
Settings for two people
Two profiles save nozzle position, water temperature and flow intensity for easy access to your preferences.
Convenient side controls
Use the side buttons or the dial to start washing or drying and adjust selected settings.
The remote provides full adjustment and user profile settings.
Explore every function
Choose a group and expand its functions.
Cleansing and dryingAdjust the flow and temperature.
Front and rear wash
Two independent water streams: a focused stream for rear cleansing and a wider, gentler stream for feminine front cleansing.
Oscillating wash
In oscillating mode, the nozzle moves back and forth to cleanse a wider area.
Nozzle position
Five settings let you adjust the nozzle position for comfortable cleansing.
Water flow intensity
Choose from five levels of water flow intensity.
Warm water on demand
On-demand heating provides warm water throughout cleansing. Adjust the temperature to your preference.
Warm air drying
Start drying after cleansing and choose the air temperature.
Hygiene and careFeatures that help keep the appliance clean.
Effective descaling
A descaling programme and a separate solution reservoir help reduce limescale, keep the water system clear and extend the service life of its components.
Odour absorption
Easy access to the container of granular activated carbon lets you replace its contents and maintain effective odour absorption throughout the toilet’s service life.
Bowl pre-wetting
Wetting the surface before use helps reduce soiling and makes cleaning easier.
Swirl flushing
A swirling flow rinses the rimless bowl. The rimless design makes the surface easier to reach when cleaning.
Automatic nozzle rinsing
The nozzle is rinsed with water before and after cleansing.
Removable nozzle tip
The removable tip provides convenient access for regular nozzle cleaning.
Water inlet filter
The filter traps particles in the incoming water. Periodic cleaning helps maintain water flow.
Automatic water renewal
The appliance automatically renews the water in its cleansing system.
Automatic flushing with CORAL
With the included CORAL frame, the toilet flushes about 5 seconds after you stand up, even if no cleansing function was used.
Comfort and controlsPersonal settings and convenient controls.
Heated seat
Set the seat temperature to suit your preferences.
Two user profiles
Save the nozzle position, water temperature and spray strength for two people. Recall the settings with user button 1 or 2.
Duroplast and soft closing
The duroplast seat and lid have a soft-close mechanism for gentle closing.
Remote, knob and buttons
Adjust the settings with the remote. The side dial and buttons operate the main functions.
Bowl lighting
Gentle lighting makes the toilet easier to use at night.
Seat sensor
The sensor detects when the seat is occupied and enables the cleansing functions during use.
Your settings, always within reach.
Choose a function, adjust its settings and save your preferences. The remote diagram explains the buttons.
Swipe sideways to see all labels.
Cleansing
Front, rear and oscillating wash. The STOP button ends the current function.
Adjustment
Nozzle position, water flow and water, air and seat temperatures.
Two profiles
User 1 and User 2 buttons recall or save your wash settings.
Drying
A dedicated button starts drying. The air temperature is adjustable.
A short press and a long press may activate different functions. See the user manual for detailed operating instructions.
Plan the set installation.
The CORAL frame and flush plate are included. Plan the frame’s water supply, waste connection and toilet power supply before finishing the wall.
CORAL frame included
Toilet fixing centres: 180 mm. The drawing below shows frame dimensions and mounting points.
Cleansing-water supply
Use the additional hose factory-routed through the frame. Connect it to the cleansing system as specified in the manual.
220–240 V power supply
Prepare an electrical cable with proper earthing, following the installation manual.
CORAL automatic-flush connection
Connect the factory-prepared connectors on the toilet and the controller inside the frame. The controller operates the flushing mechanism pneumatically. A working connection and power are required for automatic flushing; manual use of the wall button is independent.
How does flushing work?
The set flushes automatically about 5 seconds after you stand up, even if you have not used cleansing. The CLASSIC remote controls the toilet’s functions; it does not activate flushing.
The wall button operates mechanically, including during a power cut or when the toilet is switched off. Automatic flushing requires power and a connection to the CORAL controller.
Preparing the connections
The installation manual shows the toilet’s water, waste and power connections. The frame drawing is included in the dimensions section.
View installation manualDimensions and technical details
Toilet, frame and flush plate specifications, with drawings to help plan the installation.
Construction and dimensions
- Model
- CLASSIC / 4050FW
- Installation
- Wall-hung
- Dimensions (L × W × H)
- 600 × 385 × 410 mm
- Toilet weight
- 32 kg
- Fixing centres
- 180 mm
- Outlet
- Horizontal
- Bowl
- Rimless sanitary ceramic
- Seat and lid
- Duroplast; soft closing
- Finish
- White; decorative silver trim
Power supply
- Power supply
- 220–240 V, 50/60 Hz
- Rated power
- 1250 W
- Protection rating
- IPX4
Water and flushing
- Water pressure
- 0.07–0.75 MPa
- Cleansing water flow
- 0.50–0.73 l/min
- Water heating
- Instantaneous
- Maximum water heater power
- 1400 W
- Flushing
- Swirl; operated by cistern flush plate
- Automatic flushing in this set
- Yes — with the toilet connected to the included CORAL frame controller
CORAL frame — construction and installation
- Brand / series
- Major&Maker / CORAL
- Frame and flush plate model
- MM-S2003-02-B
- Application
- Wall-hung WC; drywall enclosure
- Frame width
- 500 mm
- Frame height
- 1140 mm
- Minimum installation depth, excluding wall finish
- 143 mm
- Installation depth range
- 143–203 mm
- Wall finish thickness in front of frame
- 30–105 mm
- Leg adjustment
- 0–120 mm
- Toilet fixing centres
- 180 / 230 mm
- Included flush plate colour
- black
- Service access
- By removing the flush plate
Frame — water supply and flushing
- Cistern water inlet
- G 1/2″ (DN15)
- Cleansing-water supply
- Factory-separated supply; additional hose in frame channel
- Toilet outlet connections
- Ø90 mm
- Water pressure — frame
- 0.02–0.8 MPa
- Cistern water temperature
- 5–45°C
- Manual flushing
- Conventional wall button; also works without power
- Automatic flushing in this set
- Yes, once correctly connected; requires power
- Flush volume stated in frame manual
- 6 L / 4 L
Installation depth covers the frame and its mounting; allow separately for the wall finish. The pressure values above apply to the cistern. The toilet’s own requirements are listed in its specifications.
Included installation components
- Water inlet with valve; additional cleansing-water hose.
- Frame fixings: brackets, screws and wall plugs.
- Two fixing studs / bolts for the ceramic toilet.
- Connection sleeves, flush pipe and outlet components.
- Protective covers and caps, plus the service-opening housing.
- A CORAL flush plate in the selected colour.
- Protective water-supply sleeve and spacer brackets.
- Automatic-flush controller with factory-prepared toilet connector.
Technical drawings
Dimensions and connection positions
Swipe the drawing sideways to read all dimensions.
Frame CORAL — dimensions and mounting points
Swipe the drawing sideways to read all dimensions.
Useful before installation. Essential afterwards.
CLASSIC toilet — user manual
Remote control, programmes, cleaning and maintenance.
PDF · PL / EN · Open PDFCLASSIC toilet — installation manual
Connection preparation and appliance installation.
PDF · PL / EN · Open PDFCORAL frame — installation manual
Frame and cistern installation, plus connection preparation.
PDF · Polish · Open PDFHave a question? Talk to our team.
